Plastic air-cooled pelletizer: 1. Environmentally friendly pelletizing design, strong air-cooling system, no need for water cooling, no smoke and no smell, no pollution during recycling and pelletizing.2. Low temperature pelletizing technology, does not change the nature of the recycled material, produces high quality pellets, which can be mixed with the original pellets at a high ratio, and once again produces qualified film.3. Designed with ease-of-use in mind, whenever recycling is needed, or the machine needs to be stopped, it’s just a matter of pressing a few Easy to use, whenever you need to recycle, or need to stop the machine, just press a few buttons, easy to operate.4. One time investment in the machine helps to reduce the cost of raw materials, increase profits, no more waste and residue piles up waiting to be disposed of!
Converts waste film into high quality pellets. Equipped with an advanced air-cooled heated cutter, this technology effectively converts plastic scrap into a clean, refined product. A key feature of our pelletizers is their ability to produce material that is free of gas and moisture, resulting in superior purity. This cleanliness is essential for recycling, ensuring that the end product meets stringent quality standards and can be used effectively in a variety of applications.
The heated plastic material is cut and cooled, then blown by fans into separate boxes or screening equipment for secondary processing. This ensures a thorough and comprehensive recycling process that takes your recycling efforts to new heights.
Plastic granulator application:
LDPE/HDPE/CPE/PVC/EVA/PO/PE Biodegradable Plastics
2.Model
YC-90 (manual screen changer)
Power supply: machine power voltage is 380 V, 50HZ, 3 phase
Total power: 28 kilowatts
Extruding motor: 22 kilowatts
Gearbox: 173
Inverter: 22Kw
Average power consumption: 200-250 kWh/tonne
Cutter motor: 0.75Kw
Fan motor: 1.5Kw
Screw diameter: Ø90mm
Production capacity: 100kg/hour (depends on material)
YC-110(automatic hydraulic screen changer)
Total power: 56Kw
Extrusion motor: 37Kw
Gearbox: #200
Inverter: 37Kw
Average Power Consumption: 200-250 kWh/tonne
Cutter Motor: 1.5 Kw
Fan motor: 0.75 Kw *2 and 1.5Kw*3
Screw diameter: Ø 110 mm
Production capacity: 150kg/hour (depending on material)
YC-150 (automatic hydraulic screen changer)
Power supply: Machine power voltage is 380 V, 50 HZ, 3 phases.
Total power: 65 kilowatts
Extrusion motor: 55 kW
Gearbox: #250
Inverter: 55Kw
Average power consumption: 200-250 kWh/tonne
Cutter Motor: 1.5 Kw
Fan motor: 0.75 Kw *2 and 1.5Kw*3
Screw diameter: Ø 150 mm
Production capacity: 300kg/hour (depending on the material)
3.Advantages
+Low temperature granulation
No need for strong heating to melt the plastic material, the movement of the screw generates heat, making the material semi-molten and maximizing the performance of the material.
+No tank cooling required
The pelletizer uses a constant natural air flow (generated by the blower) to cool the pellets, thus eliminating the need to deposit the extruded wire and adding water to the material.
+No air pollution
Thanks to the low-temperature technology, no waste is generated and the environment is not polluted. And due to the application of
4.Features
-Crushing/grinding and agglomeration in one go.
– The machine has a small footprint and requires only one operator.
– Easy to operate and safe to use: quick start-up of the machine. Very fast heating.
– Particles/granules are dense, uniform, high density and unbreakable . No change in color.
If you are interested in our plastic pelletizing machine – you can give me a message below – look forward to your consultation!
